Name: Landscaping

Display Field: DRAW_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This feature dataset is used for the Buena Park Engineering Plan Georeferencing Project. It contains the outlines of the plans that have been georeferenced, as well as the links to the applicable plans. This feature class is replacing the "DocumentManagement" feature class.

Service Item Id: 052922a232b34807a4074ecdf0fda838

Copyright Text: Buena Park, Norm Wray, Mina Mikhael

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6010855.478166431
YMin: 2232823.518916011
XMax: 6043650.931276172
YMax: 2274687.1399130076
Spatial Reference: 102646  (2230)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [255, 255, 0, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 40
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• UID ( type: esriFieldTypeString, alias: UID, length: 255 )
• PLAN_TYPE ( type: esriFieldTypeString, alias: PLAN TYPE, length: 255 )
• DRAW_NUM ( type: esriFieldTypeString, alias: DRAWING NUMBER, length: 255 )
• SHEET_NUM ( type: esriFieldTypeString, alias: SHEET NUMBER, length: 255 )
• DRAW_NAME ( type: esriFieldTypeString, alias: DRAWING NAME, length: 500 )
• INTERSECTION ( type: esriFieldTypeString, alias: INTERSECTION (if applicable), length: 255 )
• STREET_NAME ( type: esriFieldTypeString, alias: STREET NAME(s), length: 800 )
• PAVE_TYPE ( type: esriFieldTypeString, alias: PAVING TYPE (if applicable), length: 255 )
• SHEET_SIZE ( type: esriFieldTypeString, alias: SHEET SIZE, length: 255 )
• QA_QC ( type: esriFieldTypeString, alias: QA/QC STATUS, length: 255 )
• LINK ( type: esriFieldTypeString, alias: FILE LINK, length: 255 )
• PATH ( type: esriFieldTypeString, alias: PATH, length: 255 )
• LPATH ( type: esriFieldTypeString, alias: LOCAL PATH, length: 255 )
• COMMENT ( type: esriFieldTypeString, alias: COMMENTS, length: 800 )
• PLAN_DATE ( type: esriFieldTypeDate, alias: PLAN DATE, length: 8 )
• SCANNED ( type: esriFieldTypeDate, alias: SCANNED DATE, length: 8 )
• TempDate ( type: esriFieldTypeString, alias: Temporary Date, length: 255 )
• TempDateII ( type: esriFieldTypeString, alias: Temp Date 2, length: 255 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Shape_Length_1 ( type: esriFieldTypeDouble, alias: Shape_Length )
• Shape_Area_1 ( type: esriFieldTypeDouble, alias: Shape_Area )
• Phase ( type: esriFieldTypeString, alias: Phase, length: 255 )
• INTER_SEC ( type: esriFieldTypeString, alias: INTER_SEC, length: 255 )
• PAV_TYPE ( type: esriFieldTypeString, alias: PAV_TYPE, length: 255 )
• QAQC ( type: esriFieldTypeString, alias: QAQC, length: 255 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
